4G 3G HD Integrated IR Camera Video Wireless Transmit Audio Record
Click to View PDF Product Datasheet:
3G 4G Wireless Transmission Camera
Key Features :
- Industrial-grade design
- H.265 compression
- Support SD card up to 256G
- Optional expend HDD to 2TB
- 3G / 4G / WIFI transmission
- GPS / BD positioning
- Powerful background management system
3G/4G HD IR Camera is a professional HD camera integrated with cameras,HD video wireless transmit, audio and record. It adopts high speed processor hardware and embedded Linux system. The state of the art HD camera uses the latest IT technologies, such as H.264 codec, wireless transmitting technologies, etc. This powerful camera can be deployed on wireless and temporary surveillance application like construction place, field oil exploring, no-person station,etc.
Specification：
| Industrial design | Integrated industrial design | |||||||||
| User interface | Support E-set，remote controller, remotely operation, SD card ,etc to configure | |||||||||
| Language | English (option customized) | |||||||||
| Security | User password, Administrator password management | |||||||||
| Input/output | 1channel video input, 1 channel video CVBS output；1.0Vp-p, 75Ω | |||||||||
| OSD | Overlays letters… like date /time into the video | |||||||||
| Compression | H.264 High Profile Compression | |||||||||
| Dual stream | Record with HD video and remotely live view with lower stream | |||||||||
| Video & Live | Live | 1 channel | ||||||||
| Speed(frame rate) | PAL: 25fps， NTSC: 30fps | |||||||||
| Resolution | 720P 、D1、CIF adjustable | |||||||||
| Image quality | High, middle, and low option | |||||||||
| CIF：384 kbps、512 kbps、768 kbps、1024 kbps、1536 kbps，5 grades adjustable
D1：512kbps、768kbps、1024kbps、1536kbps、2048kbps，5 grades adjustable |
||||||||||
| Video rate | 720P：1024kbps、2048kbps、3072kbps、4096kbps、5120kbps，5 grades adjustable | |||||||||
| Compression | G.726 | |||||||||
| Storage | Support 1pcs SD card up to 256G; option for HDD expandable up to 2TB | |||||||||
| Record | Format | ASF/FAT32 | ||||||||
| Record strategy | Default power-on record, | |||||||||
| 3G/4G/WIFI | Support 3G/4G and compatible with GPRS,EDGE, etc; built-in WIFI, support hotspot | |||||||||
| GPS（option） | Support GPS, option/BD/GLONASS | |||||||||
| Firmware upgrading | SD card ; remotely upgrade; | |||||||||
| Voltage | DC: 12V/2A | |||||||||
| Power supply& consumption | ||||||||||
| Consumption | Working: ＜10W； | |||||||||
| Work Environment | Temperature | -25℃ ~ +70℃ | ||||||||
| Humidity | 10% ~ 95% | |||||||||
| Waterproof grade | IP65 | |||||||||
| Size | 140(W) x 100(H) x 380(D) mm | |||||||||
| Weight | 1780g | |||||||||
| Note: the specification is subject to change without prior notice. | ||||||||||
Application :
Armed Police;Traffic Police;Construction;Farming;Eco-Agriculture;Environmental Protection.
