Description
H2.65 ADAS DSM 1080P 4CH 4G Car DVR Mobile Dvr
Product feature
| 1.H.265 compression algorithm, high compression ratio, small storage space, greatly saves storage costs, |
| smooth network code stream, clear picture quality, multi-stream recording; |
| 2.Built-in ADAS+DSM intelligent and safe driving assistance system to provide drivers with more active and intelligent safety and reduce the incidence of safety accidents; |
| 3.Driver fatigue driving real-time monitoring and voice alert; |
| 4.Legitimate identification of driver identity to ensure legal driver driving; |
| 5.Unsafe driving behavior monitoring, capture, reporting platform; |
| 6.Lane Departure and collision warning; |
| 7.Watchdog abnormal restart function protection, better protection of machine and video files; |
| 8.Flameout time recording function (time can be set up to 24 hours); |
| 9.Support remote management, intercom, fuel consumption monitoring, fuel cut, power off function through 4G network; |
| 10.Can Expand oil Fuel sensor, temperature and humidity sensor, RFID card Rearder, tire pressure monitor, etc. through serial port; |
| 11.Support 4 channels of alarm input, can be connected (switch door, light, steering, brake, reversing, etc.), can link multiple processing responses; |
| 12.All-aluminum profile design, small size, multi-direction installation, fast heat dissipation, dustproof, shockproof; |
| Parameters | ||||
| System | Language | Chinese, English,Russian(customerized) | ||
| Operation interface | OSD menu | |||
| Password security | Password access | User password, administrator password management | ||
| GUI | Image OSD | Can be connected to an external AV display and VGA display,Remote control operation setting system parameters | ||
| interface | ||||
| Audio and video | Video input | 4-channel video input, 4pin interface, 1.0Vp-p, 75Ω | ||
| Video output | 1 channel AV composite audio and video output, 4pin interface, 1.0Vp-p, 75Ω, 1 channel VGA output,, | |||
| Audio input/output | 4 input, 1 output,4pin interface | |||
| ADAS signal input | AHD signal, resolution 1280*720, horizontal angle 67°, diagonal angle 76°, vertical angle 42° | |||
| DSM signal input | AHD signal, resolution 1280*720, horizontal angle 58, diagonal angle 70, vertical angle 45° | |||
| Audio compression format | Coding format: G726_40KBPS, sampling rate: 8000 sample bit width, 16bit sample points / per packet: 320;; | |||
| Preview function | 1 screen/2 screen/4 screen/6 screen/8 screen/9 screen split preview, support manual/event trigger full screen display function | |||
| Video resolution | Support 1080P/960P/720P/D1/HD1/CIF optional, up to 4 channels 1080P | |||
| Video quality | 1 to 8 video quality can be matched, the best level 1, the lowest level 8 | |||
| Recording rate | PAL: 100 frames/s, CCIR625 line, 50 games | |||
| NTSC: 120frames/s, CCIR525 line,60Games; | ||||
| 1080P:1536Kbps~ 8Mbps, Multi-level image quality optional | ||||
| 720P:1000 Kbps ~ 6Mbps, Multi-level image quality optional | ||||
| D1: 800Kbps ~ 3Mbps, Multi-level image quality optional | ||||
| HD1: 600Kbps ~ 2.5Mbps, Multi-level image quality optional | ||||
| CIF: 256Kbps ~ 1.5Mbps, Multi-level image quality optional | ||||
| Video mode | Default automatic recording, support for ignition recording, manual recording, alarm recording, etc. | |||
| Video storage | file format | H.265 | ||
| File system | Special file system or FAT32 | |||
| SD CARD | Support 2 large-capacity SD card recording, maximum support 256G, loop recording, automatic data coverage | |||
| Upgrade method | Support SD card / U disk upgrade | |||
| Video playback | Search video and video files by recording time, recording mode, etc. | |||
| Supports up to 4 channels of synchronized playback, pauses, fast forwards, rewinds, supports 2, 4, 8, 16 times faster forward or backward | ||||
| alarm | Alarm input | 4-channel alarm input with alarm linkage function | ||
| Alarm Output | 2-Channel alarm output | |||
| G-Sensor | Support built-in G-SENSOR acceleration sensor, alarm linkage trigger | |||
| port | RS232 | 1*RS232 | ||
| RS485 | 1*RS485 | |||
| RJ45 | 1*RJ45 | |||
| USB | 1*USB | |||
| WIFI MODULE | 3G | Built-in 3G module(WCDMA/EVDO/TD-SCDMA) | ||
| 4G | Built-in 4G module(TD-LTE/FDD-LTE) | |||
| WIFI | Built-in WIFI module(2.4G) | |||
| GPS | Support Dual Module GPS/BD, | |||
| Software | CMSV6 Client | 4G remote real-time monitoring, GPS positioning, remote management, recording, playback, intercom, monitoring, track playback, alarm processing. | ||
| Mobile phone terminal | Real-time remote monitoring, GPS positioning, recording, playback, intercom, monitoring, alarm prompts anytime, anywhere. | |||
| PC playback | Audio and video playback, GPS track playback, speed / acceleration, alarm event playback analysis. | |||
| Power | Power management | Adaptive wide-format power input with protection functions such as overload, undervoltage, short circuit, reverse connection, etc. Support for time switch and delay shutdown function. | ||
| Input voltage | DC:+8V ~ +36V | |||
| output voltage | +12V@1A,+5V@1A | |||
| working environment | temperature | -20℃ to +70℃ | ||
| humidity | 20% to 80% | |||
| Machine size | 168mm*143mm*56mm | |||
| Color box size | 20.5*14.5*20.5cm | |||
|
Carton size |
59.5*42.5*42.5cm 16pcs/Carton | |||
